What water quality is required for the SKE4?

The SKE4 operates with standard tap water. For optimal performance, water hardness of 80–350 mg/L CaCO3 is recommended. For very hard water (>500 mg/L), a softening filter is advised. The long-lasting stainless steel chamber minimizes scale buildup.

How often should SKE4 maintenance be performed?

Under normal tap water conditions, chamber cleaning 1–2 times per year is sufficient. The LCD menu interface notifies maintenance time. The stainless steel chamber, unlike plastic cylinders, can be removed and cleaned tool-free in approximately 15 minutes.

How is BMS integration done?

The SKE4 communicates with BMS/BAS systems via BACnet MS/TP or Modbus RTU protocols. With the optional Ethernet module, BACnet IP or Modbus TCP/IP are also supported. Standard RS-485 connection is sufficient for integration; web service support is also available.

Is outdoor installation possible?

Yes. The SKE4 OUTDOOR version comes with a fully insulated enclosure rated down to -40°C. Anti-freeze and overheat protection are included. No boiler room or mechanical room required.

What capacity range can be covered with SKE4?

A single SKE4 unit provides 2.7 to 136 kg/hr. For higher capacities, multiple units can be connected in parallel. Contact our technical team to determine the right model for your capacity needs.

made inCanada

⚡Steam Humidifier (Resistive)

SKE4 Electric Steam Humidifier

Name: SKE4 Electric Steam Humidifier
Brand: Neptronic

Steam Humidifier (Resistive)

Steam humidifier with 5 – 120 kg/hr capacity. Long-lasting stainless steel evaporation chamber, tool-free maintenance, optional equipment for outdoor use.

Compare

SKE4

Capacity

2,7 – 136 kg/sa

Capacity

2,7 – 136 kg/sa

Technology

Electric / Resistive

Control

BACnet / Modbus

Display

LCD 128×64

Outdoor

Available

SKE4

Steam Humidifier (Resistive)

The SKE4 series uses resistive heating elements producing mineral-free, odorless, sterile steam. The long-lasting stainless steel evaporation chamber simplifies cleaning — no plastic cylinders needed. Fast and easy maintenance via an LCD menu-driven interface. BACnet or Modbus communication enables seamless BMS integration.

Applications

Offices and commercial buildings

Hospitals and healthcare facilities

Museums and archives

Data centers

Industrial facilities

Features

Mineral-free, odorless, sterile steam production
Permanent cleanable stainless steel evaporation chamber
Patent-pending dual independent water level sensor technology
Patented Anti-Foaming Energy Conservation (AFEC) System
Fast and easy maintenance with LCD menu-driven interface
Fully insulated outdoor unit with anti-freeze and overheat protection
BACnet MS/TP or Modbus communication interface
Optional ethernet module for BACnet IP or Modbus IP with web services
Integrated scheduling system (operation, setpoints, drain cycling)
Drain water tempered below 60°C

Technical Specifications

ParameterValue

Capacity2,7 – 136 kg/sa

TechnologyElectric / Resistive

ControlBACnet / Modbus

DisplayLCD 128×64

OutdoorAvailable

CommunicationBACnet / Modbus / IP

Model Selection

Capacity & Power Table

Choose the right SKE4 model for your needs.

Model	Capacity (kg/hr)	Power (kW)	230 V (A)	400 V (A)	Steam Outlet	Steam Distribution
SKE4-E05	5	3.7	16	-	1 × Ø35 mm	SDU4-1
SKE4-E10	10	7.5	33	-	1 × Ø35 mm	SDU4-2
SKE4-E20	20	15	-	22	1 × Ø51 mm	SDU4-3
SKE4-E30	30	22	-	33	1 × Ø51 mm	SDU4-3
SKE4-E40	40	30	-	44	1 × Ø51 mm	SDU4-3
SKE4-E50	50	36	-	53	1 × Ø76 mm	-
SKE4-E60	60	44	-	64	1 × Ø76 mm	-
SKE4-E80	80	60	-	87	1 × Ø76 mm	-
SKE4-E90	90	66	-	96	1 × Ø76 mm	-
SKE4-E100	100	74	-	107	1 × Ø76 mm	-
SKE4-E110	110	82	-	119	2 × Ø76 mm	-
SKE4-E120	120	90	-	130	2 × Ø76 mm	-

Evaporation Chamber

Evaporate Water, Not Your Budget

The SKE4 series features a long-lasting, lightweight and reusable stainless steel evaporation chamber, eliminating the recurring cost of disposable plastic cylinders that require annual replacement. This engineering solution delivers thousands of Euros in savings over the unit's service life, significantly shortening the return on investment.

No tools required

No heavy lifting required

Disconnect the water inlet

No tools required

Disengage the 2 clamps

Heating elements remain fixed

Drop down with rail-guided system

Rail-guided system

System Overview

Smart Engineering Details

The SKE4 reflects engineering excellence in every detail, offering an easy-to-maintain and reliable system.

Smart Control

Integrated Multi-Platform Controller

The SKE4 controller is configured specifically for your SKE4 Steam Humidifier.

Menu-driven 128×64 LCD with 8 function buttons for faster configuration

User rights management: End User, Service Technician, Installer, Integrator

Quick Config menu for faster and easier installation

Independent scheduling system (operation & drain cycle)

Firmware upgradeable via SD card, USB or BACnet

Trending and alarm log viewing/export

Optional Features

BACnet MS/TP or Modbus menus with 75+ objects/registers for BMS and IoT integration

Ethernet module: BACnet IP or Modbus IP, web services for remote configuration and diagnostics

Steam Distribution

Steam Distribution Systems

For duct-type distribution in SKE4 resistive steam humidifiers, a Multi-Steam, S.A.M. or S.A.M.E2 steam distribution system is required.

For fan-type distribution, steam can be supplied directly into the space via an SDU without a duct network.

Multi-Steam SD

For absorption distance less than 914 mm

S.A.M. & S.A.M.E2

For absorption distance less than 1500 mm

SDU

For Models SKE4-E05 to SKE4-E40

S.A.M.E2 Technology

High Efficiency Steam Distribution

High efficiency steam distribution with specially designed steam eyelets
Double wall 304 stainless steel
Specially designed distribution eyelets prevent condensation during start-up and proportional humidity demand
High energy savings
